GTLAN ‘s OM4 multimode duplex fiber optic patch cord offers superior performance for high-speed, high-density networks. Ideal for interconnections between switches, servers and telecommunications equipment, this patch cord features SC-UPC / LC-UPC connectors, which are widely used in data center and LAN environments.
Designed with 50/125 µm OM4 fiber, it offers low loss and high transmission capacity, especially in 850 nm applications such as 10G, 40G and 100G. The violet LSZH jacket ensures fire safety and facilitates fiber type identification.
Outstanding technical characteristics:
-
Fiber type: Multimode OM4 50/125 µm
-
Connectors: SC-UPC / LC-UPC
-
Length: 2 meters
-
Hose type: Duplex
-
Cover: LSZH (violet color)
-
Outside diameter: 3 mm
-
Splint material: Zirconia ceramic
-
Minimum bending radius: 45 mm
-
Operating temperature: -20 °C to 70 °C
-
Wavelengths: 850 / 1300 nm
-
Attenuation: <3.2 / <0.8 dB/Km
-
Durability: Up to 1000 insertions
-
Certifications: CE and RoHS
-
Standards: IEC 60793, IEC 61754-20, IEC 61754-4, Telcordia GR-409
Ideal applications:
-
Data centers
-
High-speed enterprise networks
-
Backbone cabling
-
Connections between switches, routers and servers
Relying on GTLAN is betting on secure and efficient connectivity solutions, aligned with the most demanding standards of the telecommunications sector.
